Primary Applications:
All overhead irrigation, hand lines, solid sets or mechanically moved systems.
Features:
- Durable, heavy duty, all brass construction.
- Corrosion resistant Stainless Steel spring and shaft.
- Chemically resistant PTFE washers
- Dual nozzle.
Technical Specifications:
- Body trajectory: 25 Degrees
- 1/2" Male pipe connection.
- Pressure: 2.0 - 3.0 Bars.
- Flow: 1.02 - 1.74 m3/h (17.0 - 29.0 Lpm)
- Maximum spacing: 19 Mts.
- Weight: 205 Gms.
MAIN NOZZLE |
SPREADER NOZZLE |
PRESSURE AT SPRINKLER |
CASTING RADIUS |
DISCHARGE |
Dia (mm) |
Dia (mm) |
kPa |
m |
m3/hr |
LPM |
3.5 |
2.5 |
200 |
11.5 |
1.02 |
17.0 |
3.5 |
2.5 |
300 |
11.9 |
1.25 |
20.8 |
4.0* |
2.5 |
200 |
11.5 |
1.21 |
20.2 |
4.0* |
2.5 |
300 |
12.1 |
1.48 |
24.7 |
4.5* |
2.5 |
200 |
11.6 |
1.42 |
23.7 |
4.5* |
2.5 |
300 |
12.5 |
1.74 |
29.0 |
*Optional |
