Primary Applications:
All overhead irrigation, on hand lines, solid sets, permanent sets or mechanically moved systems.
Features:
- Durable, heavy duty, all brass construction.
- Stainless Steel springs.
- Chemically resistant PTFE washers.
- Stream Straightener Vane for extra coverage and wind resistance.
- Dual nozzle.
- Corrosion resistant.
- Built to last.
Technical specifications:
- Body trajectory: 30 Degrees.
- 3/4" Male pipe connection.
- Pressure: 2.0 - 4.0 Bars.
- Flow: 2.27 - 3.75 m3/h (37.75 - 62.5 Lpm)
- Maximum spacing: 25 Mts.
- Weight: 460 Gms.
MAIN NOZZLE |
SPREADER NOZZLE |
PRESSURE AT SPRINKLER |
CASTING RADIUS |
DISCHARGE |
Dia (mm) |
Dia (mm) |
kPa |
m |
m3/hr |
LPM |
5.0* |
3.0 |
300 |
15.0 |
2.27 |
37.75 |
5.0* |
3.0 |
350 |
16.0 |
2.54 |
42.33 |
5.5 |
3.0 |
300 |
16.0 |
2.55 |
42.40 |
5.5 |
3.0 |
350 |
17.0 |
2.77 |
46.10 |
6.0* |
3.0 |
350 |
18.0 |
3.15 |
52.42 |
6.0* |
3.0 |
400 |
18.0 |
3.35 |
55.75 |
6.5* |
3.0 |
350 |
18.0 |
3.49 |
58.17 |
6.5* |
3.0 |
400 |
18.0 |
3.75 |
62.50 |
*Optional |
