Primary Applications:
All overhead irrigation, hand lines, solid sets, permanent sets or mechanically moved systems.
Features:
- Durable, heavy duty, all brass construction.
- Stainless Steel spring and fulcrum pin.
- Chemically resistant PTFE washers.
- Dual nozzle.
- Corrosion resistant.
- Built to last.
Technical specifications:
- Body trajectory: 27 Degrees.
- 3/4'' Male pipe connection.
- Pressure: 2.5 - 3.0 Bars.
- Flow: 1.04 - 1.99m3/h (17-33 Lpm)
- Maximum spacing: 22 Mts.
- Weight: 380 Gms.
MAIN NOZZLE |
SPREADER NOZZLE |
PRESSURE AT SPRINKLER |
CASTING RADIUS |
DISCHARGE |
Dia (mm) |
Dia (mm) |
kPa |
m |
m3/hr |
LPM |
4.3* |
3.0 |
250 |
13.5 |
1.04 |
17 |
4.3* |
3.0 |
300 |
13.9 |
1.14 |
19 |
4.7* |
3.0 |
250 |
14.1 |
1.24 |
21 |
4.7* |
3.0 |
300 |
14.5 |
1.36 |
23 |
4.7* |
2.5 |
250 |
14.1 |
1.60 |
27 |
4.7* |
2.5 |
300 |
14.5 |
1.75 |
29 |
5.1 |
2.5 |
250 |
15.0 |
1.82 |
30 |
5.1 |
2.5 |
300 |
15.5 |
1.99 |
33 |
*Optional
|
